Alpine 600W (280W RMS) BBX Series 2 Ohm Stable 2 Channel Class A/B Car Amplifier
4.7 (79 items)
Limited Time SaleUS$83.99 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 238009139 | Release Date | 2026/07/11 | List Price | US$56.00 | Model Number | 238009139 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
<p>No one ever wanted to drive around with their windows down and the music turned... down low. Turn your music up with Alpine 600W BBX Series Class-A/B Amplifier.This amplifier can use 2 or 1 channels for your convenience. It utilizes a high-efficiency digital circuit design for the best performance.High pass and low pass filters let you control the frequency for bass range levels. These filters let you match your speakers and ensure optimum efficiency.Blast the stereo with an amplifier that can handle it. Invest in the Alpine 600W BBX Series Class-A/B Amplifier.</p>
- High efficiency digital circuit design
- Features adaptive feedback global modulation topology
- High pass and low pass filters let you set the frequency points for the high, mid, and bass ranges to match your speakers and ensure optimum efficiency
- Includes variable bass EQ
- Utilizes 2 or mono channel operations for your convenience
- Specifications
- Terminal Layout: Two-Sided
- Screw Mount / Wire Cover: Integrated Wire and Mounting Screw Terminals
- Amplifier Type: Class-A/B
- Channel Design: 2/1 Channel
- Thermal Control: Thermal Management Control
- Power Supply: DC-DC PWM Power Supply
- Power Supply Design: MOSFET Power
- Current Protection: Over-Current, Over-Voltage and Thermal Protection
- Crossover: Variable Low-Pass / High-Pass
- Green/red Status LED
- 1 pair RCA pre-inputs
- 1 pair RCA pre-outputs
- Total Max Power: 300W
- Crossover Frequency (Variable, OFF/LPF/HPF Selectable)
- 1/2 Ch: LP: 50Hz ? 250Hz HP: 80Hz ? 1.2kHz
- EQ (Equalizer): Bass EQ Fixed Frequency 45 Hz, Q=0.5, Variable Gain 0dB to +12dB
- Power Requirements: 14.4 V DC (11 V to 16 V)
- Input Sensitivity: 0.2
- 8.0 V
- Frequency Response: 5 Hz
- 50 kHz (+ 0,-3 dB)
- Speaker Impedance: 4 or 2 O
- Signal to Noise: S/N Ratio (IHF A Weighted, Reference: rated power into 4ohms) 95 dB
- RMS Power Ratings
- Per Channel into 4ohms (=1%THD+N): 2 x 50W
- Per Channel into 2ohms (=1%THD+N): 2 x 70W
- Bridged into 4ohms (=1%THD+N): 1 x 130W
- Color: Black
- Dimensions (L x W x H): 9.44 x 9.84 x 2 inches
- Weight: 4.2 pounds
- Manufacturer warranty: 1-year warranty
| Brand | Alpine |
|---|---|
| Rms power rating | 280 W |
| Channels | 2 |
| Impedance | 2 ohm |
| Peak audio power handling | 600 W |
| Input/output type | RCA |
| Rec. use | Car, Performance |
| Size | 10.4" x 15.6" x 3.1" |
| Color | Black |
| Audio output | 280 W |
| Total harmonic distortion | 1 % |
| Signal-to-noise ratio | 95 dB |
| Items included | A/B Car Amplifier, 1 pair RCA pre-inputs, 1 pair RCA pre-outputs |
| Accessories | 1 pair RCA pre-inputs, 1 pair RCA pre-outputs |
| Inputs/Outputs | 1 pair RCA pre-inputs 1 pair RCA pre-outputs |
| Input/output quantity | 2 |
| Input/output direction | Bi-Directional |
| Model | BBX-T600 |
| Vehicle type | Car |
| Vehicle fitment type | Universal |
| Assembled product weight | 4.2 lbs |
| Volts | 14.4 V |
